Description

No job is too large for this heavy-duty drill press. This unit features the 4203 adjustable-position, variable-speed base and the 4292-1 1¼-in drill motor. Built for production drilling, this 11.5-amp drill press can handle the toughest drilling jobs with up to a 1-¼” threaded hole capacity. The two-speed motor runs at 375 and 750 RPM, geared low for maximum torque. It can produce up to 1600 pound of drill point pressure with a 1-inch steel plate.

Feedback speed control helps you maintain speed during operation. This unit features a No. 3 Morse Taper Chuck, for fast and easy bit changes while eliminating slippage and breakage. The dual-mount gear case with reverse mount permits tight quarter drilling. Use with the larger 4203 adjustable base (sold separately) for the toughest applications.

  • Powerful 11.5-amp motor: Engineered for the toughest applications, delivering 375/750 RPM
  • Dual-Mount Gear Case/Reverse Mount: Permits tight quarter drilling
  • 1-1/4” Capacity: Taps up to 1-inch, 14-threaded holes
  • Maximum force: Develops up to 1600 pounds of drill point pressure with a 1-inch steel plate
  • Solid state electronic switching: Offers faster, smoother and quieter switching for a longer product lifespan
  • Line Lockout: Prevents tool from operating if voltage is restored to an interrupted line
  • Weight 72.0 lbs
    Voltage 120V AC
    Cord Type 9′ Fixed
    Electronic Feedback Yes
    No Load RPM 0-750, 0-375
    Amps 12.5
    Construction Type Grounded
    Adjustable Base Yes
    Drill Travel 11″
    Chuck or Taper No. 3MT
    Drill Capacity 1-1/4″
    Drill Point Pressure 1,530/1,600 lbs
    Tap Capacity 1″-14
