Description

Equipped with high-speed running gear. Ideal for highway towing. Its’ coolbox design allows inside temperature to remain no more than 20° above outside air temperature, which extends component life and eliminates long, cool down periods. A large capacity fuel tank provides at least 8 hours of operation under full load. Easy-to-maintain, side-by-side coolers ensure optimum performance in demanding conditions.

COMPRESSOR FEATURES
Two-stage, heavy duty, dry type air cleaner with replaceable element located inside the enclosure.
25-micron spin-on oil filter element.
Oil separation system; two-stage vertical tank with sight gauge and over-fill protection.
Air-to-oil finned tube oil cooler.
Engine direct driven flexible coupling.
Engine Features

Two-stage, heavy duty, dry type air cleaner with replaceable element located inside the enclosure.
Oil drain access cover.
Electric starting system with 700 CCA battery.
Make/Model JD 4045D
Rated BHP 80 bhp
Safety Features

Starter protection prevents engagement while alternator is turning.
Automatic safety shutdowns: high discharge air temperature, low engine oil pressure, and high
engine coolant temperature.
Manual and automatic blowdown valves.
Minimum pressure device.
ASME safety relief valve.
Fan guard meets OSHA requirements.
Towing safety chains with safety hooks.
Trailer lighting complies with US DOT/Federal MVSS 108.
Operating and maintenance manuals.
Operating and safety decals.
Dimensions

Approx. Work Weight 2505 lbs.
Height (Including Tailpipe) 62 ”
Length (Including Drawbar) 141.3 ”
Width 68.5 “
